frame
KELLYS THEOS R-series - advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / Think Link® suspension system, 130 mm rear travel, integrated removable battery, 1.8" tapered HT, post mount 203 mm, mullet 29" / 27.5"+ wheelset, 12x148 mm Boost thru axle
motor
PANASONIC GX Ultimate, 95 Nm, 36 V
battery
KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ
switch unit
PANASONIC
computer display
PANASONIC Bluetooth® 5.0 navigation Side Color Display
fork
ROCK SHOX 35 Silver TK (29") Boost, 150 mm, Solo Air / TurnKey / Maxle Stealth 15 mm thru axle
rear shock
ROCK SHOX Deluxe Select R, DebonAir+ (210x55 mm)
crankset
MIRANDA Miranda (34T) - length 170 mm
rear derailleur
SHIMANO Cues U6000 (direct mount)
shifters
SHIMANO Cues SL-U6000-10 Rapidfire Plus
speed
10
cassette sprocket
SHIMANO Linkglide CS-LG400-10 (11-48T)
chain
SHIMANO Linkglide CN-LG500 (122 links)
brakes
SHIMANO MT420 / MT410 hydraulic disc
brake levers
SHIMANO Deore BL-M4100
brake rotors
SHIMANO RT30 203 mm front / EM300 203 mm rear
hubs
SHIMANO MT400-B Disc Center Lock (32 holes)
rims
KLS Valor 3 Disc 622x30 front / 584x30 rear (32 holes)
spokes
stainless steel black
head parts
ACROS 1.8 tapered semi-integrated
thru axle
ROCK SHOX Maxle Stealth 15x110 mm front / Mr. Control 12x177 mm rear
stem
KLS Alm/En 50 - diam 28.6 mm / bar bore 31.8 mm / length 60 mm
handlebar
KLS Alm/En 70 RiseBar - diam 31.8 mm / rise 25 mm / width 780 mm
grips
KLS Poison OneLockon
seat post
LIMOTEC A1 Remote Telescopic - diam 30.9 mm / length 445 mm, travel 150 mm
saddle
fi’zi:k Taiga, S-alloy rails
pedals
plastic
frame size
S
rear tyre
SCHWALBE Nobby Nic Performance 65-584 (27.5"x2.60) Tubeless Easy, ADDIX, folding
front tyre
SCHWALBE Nobby Nic Performance 60-622 (29"x2.35) Tubeless Easy, ADDIX, folding
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
